Bagaimana cara membuat
desain yang siap dilaser di Adobe Illustrator®
![](/static_processed/492ebf445320511532c163003f0b53c6/adobe-illustrator-logo-760x584-e0c.jpg?{"image":"https://backend.troteclaser.com/static/images/knowledge/tips-tricks/how-to-print-from-adobe-illustrator/adobe-illustrator-logo-760x584-e0c.jpg","edits":{"extract":{"top":13,"left":0,"width":760,"height":570},"resize":{"width":640,"fit":"cover"}},"outputFormat":{"format":"webp"}}){kind=logo}
Alternatif untuk CorelDraw®
Berkali-kali kami mendapat pertanyaan: "Apakah saya benar-benar perlu bekerja dengan CorelDraw®? Saya lebih suka mengedit desain saya di program lain, seperti Adobe Illustrator®." Jawabannya? Tidak masalah. Gunakan panduan ini untuk menentukan pengaturan optimal.
Panduan untuk pengaturan yang optimal
Pilih pengaturan berikut tepat di awal untuk memastikan bahwa laser dapat menginterpretasikan informasi grafis dengan tepat.
Langkah Bertahap
![Create your graphic in Adobe Illustrator](/static_processed/282d5c4531ecb37159c1984718035164/.PNG?{"image":"https://backend.troteclaser.com/static/images/knowledge/tips-tricks/how-to-print-from-adobe-illustrator/adobe-illustrator-create-graphic.PNG","edits":{"resize":{"width":640,"fit":"cover"}},"outputFormat":{"format":"webp"}})
Langkah 1: Ruang warna RGB
Use following settings in Adobe Illustrator:
- Line width for cut lines must be 0.001 mm
- Use RGB color space (the same like in the Job Control material database)
- The stroke must be aligned to the center
![Adobe Illustrator: Set line color](/static_processed/6d94e70c1e7ba1a41906a3f3f41c06ec/.PNG?{"image":"https://backend.troteclaser.com/static/images/knowledge/tips-tricks/how-to-print-from-adobe-illustrator/adobe-illustrator-set-line-color.PNG","edits":{"resize":{"width":1680,"height":800,"fit":"inside"}},"outputFormat":{"format":"webp"}})
![Adobe Illustrator: Set Color Mode](/static_processed/91c037f249617be37f157489f4299da2/.PNG?{"image":"https://backend.troteclaser.com/static/images/knowledge/tips-tricks/how-to-print-from-adobe-illustrator/adobe-illustrator-color-mode.PNG","edits":{"resize":{"width":1680,"height":800,"fit":"inside"}},"outputFormat":{"format":"webp"}})
![Adobe Illustrator: Set Line Width](/static_processed/4d2150d6e129ef044351c07e826379ec/.PNG?{"image":"https://backend.troteclaser.com/static/images/knowledge/tips-tricks/how-to-print-from-adobe-illustrator/adobe-illustrator-set-line-width.PNG","edits":{"resize":{"width":1680,"height":800,"fit":"inside"}},"outputFormat":{"format":"webp"}})
![Adobe Illustrator: Set Align Stroke Center](/static_processed/1c8166714f735a59dbee092e0387238e/.PNG?{"image":"https://backend.troteclaser.com/static/images/knowledge/tips-tricks/how-to-print-from-adobe-illustrator/adobe-illustrator-align-stroke.PNG","edits":{"resize":{"width":1680,"height":800,"fit":"inside"}},"outputFormat":{"format":"webp"}})
![](/static_processed/407309fb113fd3999c0eda1f58f15441/illustrator-print-settings-laser-engraving-760x750-457.jpg?{"image":"https://backend.troteclaser.com/static/images/knowledge/tips-tricks/how-to-print-from-adobe-illustrator/illustrator-print-settings-laser-engraving-760x750-457.jpg","edits":{"resize":{"width":640,"fit":"cover"}},"outputFormat":{"format":"webp"}})
Langkah 2: Lanjutkan ke dialog cetakan
Sekarang desain Anda sudah siap, dan Anda ingin mengirimkannya ke laser. Sama seperti CorelDraw®, Adobe Illustrator® juga berkomunikasi dengan laser melalui dialog pencetakan.
![print dialogue illustrator](/static_processed/b2e950b8f9c53053e6e3ab18ad845593/.jpg?{"image":"https://backend.troteclaser.com/static/images/knowledge/tips-tricks/how-to-print-from-adobe-illustrator/printerdialog_AI.jpg","edits":{"resize":{"width":640,"fit":"cover"}},"outputFormat":{"format":"webp"}})
Langkah 3: Pilih Pengukir Trotec dan masukkan parameter laser
Sekarang pilih Pengukir Trotec, dan dalam "Preferensi" atau "Pengaturan" Anda dapat menyesuaikan pengaturan laser. Setelah selesai, klik "Cetak," dan Anda akan secara otomatis diarahkan ke JobControl®.
![Adobe Illustrator: Set printing parameters](/static_processed/36310fda911a47aa3a229849f8d25170/.PNG?{"image":"https://backend.troteclaser.com/static/images/knowledge/tips-tricks/how-to-print-from-adobe-illustrator/adobe-illustrator-set-printing-parameters.PNG","edits":{"resize":{"width":640,"fit":"cover"}},"outputFormat":{"format":"webp"}})
Step 4: Set the printing parameters
- Set the size: Width and Height must be bigger or equal the graphic size
- Mark "Minimize to Jobsize" if you only want to print visible areas of the job.
- Chose the material settings from the material database.
- Click the JobControl® logo button to print
![Adobe Illustrator: Printer settings](/static_processed/cc2a80a8bd54239261eb114cb27ee1bf/.PNG?{"image":"https://backend.troteclaser.com/static/images/knowledge/tips-tricks/how-to-print-from-adobe-illustrator/printing-from-illustrator.PNG","edits":{"resize":{"width":640,"fit":"cover"}},"outputFormat":{"format":"webp"}})
![Adobe Illustrator: Set Printing area](/static_processed/1524c5c8d02ea2a31d8396e04b6a2aa5/.PNG?{"image":"https://backend.troteclaser.com/static/images/knowledge/tips-tricks/how-to-print-from-adobe-illustrator/adobe-illustrator-set-printing-area.PNG","edits":{"resize":{"width":640,"fit":"cover"}},"outputFormat":{"format":"webp"}})
Langkah 5: JobControl®
Sekarang pilih Pengukir Trotec, dan dalam "Preferensi" atau "Pengaturan" Anda dapat menyesuaikan pengaturan laser. Setelah selesai, klik "Cetak," dan Anda akan otomatis diarahkan ke JobControl di sini.
Informasi lebih lanjut
Hubungi hotline layanan Trotec di mana pakar laser termotivasi dan berkualitas tinggi akan membantu Anda dengan pertanyaan atau masalah apa pun.
