Compact integration laser for industrial marking

The InMarker series powerful (up to 200 watts) industrial laser engravers guarantee precise marking with short cycle times as part of your production line, robot cell or production facility.

Contact us

Marking laser for the labelling of metals and plastics.

Flexibility across the industry

The design of the InMarker marking lasers is both compact and lightweight, enabling it to be used within multiple industries and production units. Weighing just 4.6 kg, the InMarker is one of the lightest integration lasers on the market.

Simple integration

Full safety documentation and fieldbus interfaces, such as Profinet, as well as step-by-step installation instructions etc. are all provided for optimal support of the integrator with laser integration.

Powerful and stable

Irrespective of the data that is being labelled, the InMarkers are designed for consistent precision labelling on an ongoing basis in short cycle times, even when used as part of shift work (24/7)

Fiber laser & MOPA Laser

There is also an option to fit them with 20, 30 or 50 watt pulsed Yb fiber laser sources or with 20 or 100 watt MOPA laser sources and these lasers produce perfect annealing marking and surface engraving.

Robust and compact marking device

Remaining one of the smallest integration lasers on the market, the InMarker is suitable for harsh environments due to its robust housing and IP 54 protection class.

Safe working environment

The optional SafetyCone is the perfect safety-related solution for laser operations (up to class 1) without the need for protective housing.

Overview of the integration laser

InMarker
VIN Marker
Safetycone
Customised laser solutions
Industry specialists

Fiber laser and MOPA for labelling metal and plastics

The powerful industrial laser engravers guarantee precise labelling with short cycle times as part of your production line, robot cell or production facility.

More about the InMarker

Would you like to find out more about our industrial solutions?

Contact us

Fiber laser and MOPA for labeling metal and plastics InMarker

Technical data for InMarker

Model InMarker
Laser source pulsed Yb-Fiber laser
Wave length 1064 nm
Laser power 20 W 30 W 50 W 20 W 100 W
Laser class possible with Safetycone and pilot laser class 2, possible with Safetycone without pilot laser class 1 and without Safteycone laser class 4
Pilot laser yes - red (optional without pilot laser)
Pulse duration 200 ns Adjustable Adjustable
2-350 ns 2-500 ns
Pulse frequency 1-600 kHz 1-4000 Khz
Max. Pulse energy  0,8 mJ  0,8mJ (@37kHz) 1,25mJ (40kHz) 0,8mJ (@25kHz) 1,5mJ
(@ 25kHz) (@67kHz)
Typical service life of pump diodes 100.000h
Jet quality M²<1,5 M²<1,8 M²<1,4 M²<1,6
Marking field with Safetycone Variant S - marking field X x Y: 50 x 40 mm / top surface: 80 x 70 mm
only possible with focal length 160 or 163 mm Variant L - marking field X x Y: 90 x 70 mm / top surface: 120 x 100 mm
  Alternative variants: customized
Marking field without Safetycone 70 x 70 mm, 120 x 120 mm, 150 x 150 mm,
190 x 190 mm, 240 x 240 mm, 310 x 310 mm
Focal length selectable: 100 mm, 160 mm, 210 mm, 254 mm, 330 mm, 420 mm
Fieldbus / control Profinet
Communication Ethernet, USB, HDMI
Security interface Standard: Han 3A 6pol, Option: Profisafe / Han3A RJ45
Suction interface Harting Han 6 24pole
Cooling active air-cooled
IP Protection class IP 54 (marking head)
Power consumption Max. 1.000 W
Power supply 110 - 230V / 50-60Hz / 1-N-PE
Laserrack Interfaces & integrated power supply
Safetycone Interfaces & integrated power supply
Fiber length Standard: 3 m / Option: 5 m
Connection package head/rack Standard: 3 m / Option: 5 m
Connection head/rack Hybrid cabel 1,5m
Operating environment marking head 15 - 35 °C, non-condensing
Operating environment rack 15 - 35 °C, 0 - 60 % non-condensing
Weight marking head 4,6 kg
Weight Safetycone Variant S: 2,8 kg, Variant L: 3 kg
Weight laser rack 19'' 4HE 13 kg 16 kg 13 kg 18 kg
Weight control rack  19'' 4HE 14 kg
Dimensions marking head 306 x 120 x 106 mm
Dimensions Safetycone 209 x 183,5 x 269,5 mm
Dimensions laser rack  19'' 4HE 450 x 177 x 540 mm
Dimensions control rack  19'' 4HE  450 x 177 x 540 mm
Applied standards and guidelines IEC EN 60825-1, Machinery Directive 2006/42/EG

Options

Marking area
With Safetycone 50 x 40 mm / 90 x 70 mm
ithout Safetycone, depending on the lens, up to 190 x 190 mm

Safetycone
The local “Safetycone” safety module allows work to take place under the highest possible laser safety class 1, thereby saving the cost, effort and space associated with an additional laser protective housing.
Designed for flat surfaces. It is possible to customise the Safetycone if the surface is curved or bent.

Pilotlaser
As standard, the InMarker is supplied with a pilot laser that meets laser protection class 2 in conjunction with the Safetycone. It is possible to optionally cancel the pilot laser (it cannot be retrofitted).

Customising
For all non-standard versions, our Competence Centre  can provide a feasibility study for your specific usage.

Cable length
5 m trailing

Direct part marking with laser

Perfect for industrial marking (DPM)

Direct Part Marking (DPM) is a type of marking that is applied directly to the workpiece and permanently remains in place. Compared to dot peen marking (needle embossing), laser marking is contactless, thereby allowing reliable labelling to take place in production without the need for interruptions that are time-consuming and cost-intensive. No scratching of tools or components, no smudged markings.  Milling parts are marked with series and batch numbers, cast parts are engraved with data matrix codes or injection-molded parts are provided with production dates and serial numbers. It is therefore possible to quickly implement practically any industrial labelling (DPM) in short cycle times without fixing the material.

Applications and areas of use

The InMarker can be easily integrated into your production line or installed in stand-alone workstation without the need to make costly changes to your production. This solution can therefore be used to directly implement any industrial labelling in short cycle times without fixing the material.

References from industry

+
+
+
+
+

Industry specialists for your series and integration requirements

Our expert team in Key Accounts will provide you with advice and support from the very first meeting through to carrying out a feasibility study, training and commissioning. This team and the support of an additional 750 employees across the world provide you with a competent and reliable partner for your industrial processes.
